Parametric Shaft Modeler is a technology demonstration of creating multi-diameter shafts based on the sophisticated geometric kernel, highlighting the potential to enhance design processes across multiple sectors such as CAD software companies, third-party developers, engineering and design companies, manufacturing firms, product development teams, and simulation and analysis firms.
Parametric Shaft Modeler offers the following functionality:
- Adding and removing shaft sections.
- Connecting shaft sections.
- Adjusting a shaft section size.
- Adding features to sections—fillets, chamfers, keyways, grooves, wrenches, and so on.
- Previewing a shaft in 2D.
- Generating a shaft.
- Modifying shaft configurations.
- Serializing a 3D model.
- Viewing a model in 3D.
Requirements:
- Windows® 10
Watch a short demo video below to see the current functionality of the Parametric Shaft Modeler technology demonstration.
If you are interested in learning more about the demonstrated technologies and how they can be utilized for your organization’s needs, please contact us to discuss the details.
