Generative Design for Legacy CAD is a technology demonstration of establishing seamless integration between SOLIDWORKS® CAD software and the ELISE™ visual programming software platform to modify CAD models by using generative engineering technology.

Generative Design for Legacy CAD offers the following functionality: 

  • Creating new features in ELISE to design new workflows
  • Setting input parameters
  • Applying features to SOLIDWORKS models to modify them
  • Saving results as separate features in the SOLIDWORKS feature tree
  • Recomputing features after changes to the SOLIDWORKS models

Requirements:

  • Windows 10, 64-bit, version 1703 or later
  • SOLIDWORKS 2021
  • ELISE 2.0

To see the Generative Design for Legacy CAD technology demonstration in action, watch a short demo video below.

If you are interested in learning more about the demonstrated technologies and how they can be utilized for your organization’s needs, please contact us to discuss the details.
